The IICUC01 functions as a universal controller module for ABB Bailey distributed control systems. This ABB unit executes advanced regulatory and logic control for continuous processes. We engineered this module to deliver reliable automation for power generation and industrial applications.
Technical Specifications and Design Features
This DCS controller module weighs approximately 0.78 kilograms. Its dimensions measure 280 millimeters in height, 40 millimeters in width, and 280 millimeters in depth. The unit features a rugged metal housing with integrated edge connectors for backplane installation.
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model | IICUC01 |
| Category | DCS Controller Module |
| Product Line | Bailey INFI 90 |
| Processor Type | 32-bit RISC |
| Memory | 2 MB RAM, 1 MB Flash |
| Processing Speed | 0.10 µs per instruction |
| Loop Capacity | 128 PID loops |
| I/O Capacity | 2,048 digital, 256 analog |
| Communication Ports | 2 x Module Bus, 1 x RS-232 |
| Backup Battery | Lithium 3.6V (integrated) |
| Power Consumption | 4.5 W from backplane |
| Operating Temperature | 0°C to 60°C |
| Dimensions (H x W x D) | 280 mm x 40 mm x 280 mm |
| Weight | 0.78 kg |
Engineers will appreciate the comprehensive control capabilities of the IICUC01. This controller handles up to 128 PID loops for precise process regulation. Consequently, users can manage complex applications like boiler control, turbine monitoring, and chemical processing.
Furthermore, the 32-bit RISC processor executes instructions in just 0.10 microseconds. This speed enables fast response to process disturbances and alarm conditions. The IICUC01 provides 2 megabytes of RAM for program execution and data storage.
Energy Storage and Data Integrity
The IICUC01 includes a lithium 3.6V backup battery for critical data preservation. This battery maintains PID tuning parameters, setpoints, and alarm limits during power interruptions. Engineers can trust this energy storage to protect valuable configuration data in the field.
System Integration and Communication
You can install this controller module in any INFI 90 rack system. The IICUC01 communicates with I/O modules through dual Module Bus ports. This redundant communication architecture ensures continuous operation during bus failures.
The module includes an RS-232 port for programming and diagnostic access. This port connects directly to engineering workstations for configuration and monitoring. For reference, other Bailey INFI 90 controllers share this same communication architecture.
I/O Management and Performance
The IICUC01 manages up to 2,048 digital I/O points and 256 analog channels. This capacity suits medium to large-scale process applications. The module supports multiple control strategies including cascade, feedforward, and ratio control. Diagnostic LEDs provide immediate feedback for power, run, and communication status.
