ABB 07 KT 240D R1: Compact Configuration Unit for Procontic Systems

The ABB 07 KT 240D R1 functions as a dedicated basic configuration unit. This tool programs Procontic programmable controllers directly on the factory floor. You can use it for logic edits without any external computer. Its rugged housing withstands dust, vibration, and temperature fluctuations.

Technical Specifications and Hardware Details

This configuration unit measures 265 mm in width. Its height reaches 185 mm, and the depth equals 60 mm. The ABB 07 KT 240D R1 weighs only 1.2 kilograms. This lightweight design allows easy handheld operation or panel storage. The unit contains a single main PCB with all processing logic. It uses no internal battery for program retention. Instead, it relies on EEPROM memory for non-volatile storage. You will find one 25-pin D-sub connector for controller communication. A separate 8-pin DIN socket provides external power input.

Display and User Interface Features

The ABB 07 KT 240D R1 includes a 4-line LCD display. Each line shows 20 alphanumeric characters clearly. This screen provides real-time ladder logic monitoring. Below the display, you will find 24 tactile membrane keys. These keys include navigation arrows and function shortcuts. Consequently, you can enter or modify program steps quickly.

Operational Guidance and Practical Use

You must connect this unit to a Procontic controller via the D-sub cable. Transitioning to programming mode, press the “PROG” key for two seconds. The unit consumes only 5 watts during active use. For storage, keep the device in its protective carry case. Additionally, the EEPROM retains your program for over ten years.
