Honeywell CC-PWRR01 51198685-100 Redundant Power Supply Module

Overview

The Honeywell CC-PWRR01 Redundant Power Supply Module is part of the Series C power system, providing 24 Vdc power to compatible Series-C components. This power system includes redundant power supplies and supports backup battery power for enhanced reliability. With modular design for easy maintenance and tailored capabilities, it is ideal for use in critical applications where continuous power is necessary.

Notable Features

• Modular “Blade” design for easy field maintenance
• Space-efficient design
• Redundant power supply for continuous power availability
• Optional battery backup for up to 30 minutes at 20A (only available in 20A power system)
• Seamless switch operation between power supplies or battery backup
• Visual and point contact alarms on all power system components
• Full Series-C HAZLOC Approvals

Detailed Specifications

Power System

• AC Input (VAC, rms): 100-230V (Operating Band) / 85-264V (Operating Limits)
• Frequency (Hz): 47-63 Hz
• Holdup Time: 20ms
• Output Voltage (VDC): 24-26VDC
• Battery Backup (UPS): 30 minutes at 20A max (Only available for 20A system)
• Output Current:
  • 20A Power System: 0-20 amps
  • 40A Power System: 0-40 amps
• Efficiency: 65% minimum
• Input Current @ 120/240 VAC Line:
  • Inrush/Rerush: 35A peak max
  • Running (max): 5.5 Amps rms @120V / 2.7 Amps rms @240V
  • Power Factor: 0.95 minimum
• Ambient Temperature:
  • Range: 0 to 60°C
  • Max Rate of Change: 0.25°C/min for 20A, 1°C/min for 40A

Additional Notes

• Battery Backup is only available with the 20A Power System
• The 40A Power System requires three AC mains power feeds for operation

Model Numbers

• Description: Power System (20A), redundant (2 power supplies), 120/240 VAC
• Model: CC-PWRR01
• Part Number: 51198685-100
• Spare/Loose Items: 20A Power Supply
