Foxboro P0916AG Field Terminal Assembly

Overview

The Foxboro P0916AG is a highly reliable field terminal assembly designed for the Foxboro FBM204 analog input module. This device offers an efficient, convenient way to connect field devices to the FBM204. It supports up to four analog sensors, making it ideal for various industrial applications. The P0916AG ensures high-quality performance with excellent protection against electrical interference.

Key Features

Compact Design: The P0916AG features a space-saving design, making it easy to install in cabinets and enclosures.
Galvanic Isolation: It offers galvanic isolation, ensuring that field devices are protected from electrical noise and interference.
Rugged Construction: Built with durable materials, the P0916AG can withstand harsh environments, ensuring long-term reliability.
Easy Installation: The P0916AG is easy to install and configure. It requires no special tools or software, streamlining the setup process.

Technical Specifications

Parameter	Specification
Manufacturer	Foxboro (now part of Schneider Electric)
Model Number	P0916AG
Product Type	Field Terminal Assembly
Supported Devices	Up to 4 analog sensors
Isolation	Galvanic isolation between field devices and module
Mounting	DIN rail or panel mountable
Operating Temperature	-20°C to +70°C (-4°F to +158°F)
Dimensions (L x W x H)	Approx. 10.2 cm x 5.3 cm x 3.5 cm
Weight	Approx. 0.3 kg (0.66 lbs)
Material	Rugged plastic and metal

Applications

The Foxboro P0916AG is ideal for use in several industrial automation sectors:

Process Control: It connects field devices to control systems, providing precise signal processing.
Industrial Automation: The module offers seamless integration with analog systems for efficient monitoring and control.
Building Automation: It facilitates the connection of sensors for building management systems, enhancing system performance.
